Product Summary

The LCMXO1200C-3TN144C is a Lattice CPLD. It is optimized to meet the requirements of applications traditionally addressed by CPLDs and low capacity FPGAs.

Parametrics

Absolute maximum ratings: (1)Supply Voltage VCC:-0.5V to 3.75V; (2)Supply Voltage VCCAUX:-0.5V to 3.75V; (3)Output Supply Voltage VCCIO:-0.5V to 3.75V; (4)I/O Tristate Voltage Applied:-0.5V to 3.75V; (5)Dedicated Input Voltage Applied:-0.5V to 4.25V; (6)Storage Temperature (ambient):-65℃ to 150℃; (7)Junction Temp.:+125℃.

Features

Features: (1)Instant-on-powers up in microseconds; (2)Single chip, no external configuration memory required; (3)Excellent design security, no bit stream to intercept; (4)Reconfigure SRAM based logic in milliseconds; (5)SRAM and non-volatile memory programmable through JTAG port; (6)Supports background programming of non-volatile memory; (7)256 to 2280 LUT4s ; (8)73 to 271 I/Os with extensive package options; (9)Density migration supported; (10)Lead free/RoHS compliant packaging.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
LCMXO1200C-3TN144C
LCMXO1200C-3TN144C
Lattice
CPLD - Complex Programmable Logic Devices 1200 LUTS 113 I/O
Data Sheet
0-1: $8.37
1-25: $7.29
25-100: $6.71
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
LCMXO1200C-3TN144C
LCMXO1200C-3TN144C
Lattice
CPLD - Complex Programmable Logic Devices 1200 LUTS 113 I/O
Data Sheet
0-1: $8.37
1-25: $7.29
25-100: $6.71
LCMXO1200C-4TN144C
LCMXO1200C-4TN144C
Lattice
CPLD - Complex Programmable Logic Devices 1200 LUTs 113 IO 1.8 /2.5/3.3V -4 Spd
Data Sheet
0-1: $9.63
1-25: $8.37
25-100: $7.76
LCMXO1200C-5TN144C
LCMXO1200C-5TN144C
Lattice
CPLD - Complex Programmable Logic Devices 1200 LUTS 113 I/O
Data Sheet
0-1: $11.04
1-25: $9.63
25-100: $8.89
LCMXO1200E-3BN256C
LCMXO1200E-3BN256C
Lattice
CPLD - Complex Programmable Logic Devices 1200 LUTs 211 I/O 1.2V -3 SPD
Data Sheet
0-1: $8.43
1-25: $7.32
25-100: $6.90
LCMXO1200E-4M132I
LCMXO1200E-4M132I
Lattice
CPLD - Complex Programmable Logic Devices 1200 LUTs 101 IO 1.2 V -4 Spd I
Data Sheet
0-1: $10.65
1-25: $9.27
25-100: $8.59
LCMXO1200E-3FT256I
LCMXO1200E-3FT256I
Lattice
CPLD - Complex Programmable Logic Devices 1200 LUTs 211 IO 1.2 V -3 Spd I
Data Sheet
0-1: $10.80
1-25: $9.42
25-100: $8.70
